Description SPINDLE SET (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $209.78
Ref No 2
Part Number 75160-V09-D01
Description PULLEY, DRIVEN (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $26.94
Ref No 3
Part Number 76120-V09-D01
Description ARM A, TENSION
Serial Range 1000001 - 9999999
Qty
Price $57.22
Ref No 4
Part Number 76122-V09-D01
Description SPRING, TENSIONER
Serial Range 1000001 - 6101760
Qty
Price $15.40
Ref No 4
Part Number 76129-V09-A01
Description SPRING, TENSIONER
Serial Range 6101761 - 9999999
Ref No 5
Part Number 76123-V09-D01
Description ARM B, TENSION
Serial Range 6101761 - 9999999
Qty
Price $24.86
Ref No 6
Part Number 06762-V09-A01
Description BRACKET, TENSIONER (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 6101760
Qty
Price $157.58
Ref No 6
Part Number 76126-V09-A01
Description BRACKET, TENSIONER
Serial Range 6101761 - 9999999
Ref No 7
Part Number 76128-V09-A01
Description ROD, TENSIONER (NOT AVAILABLE)
Serial Range 6101761 - 9999999
Ref No 7
Part Number 76128-V09-D01
Description ROD, TENSIONER
Serial Range 1000001 - 6101760
Ref No 8
Part Number 76130-V09-D01
Description ROLLER A, TENSIONER (NOT AVAILABLE)
Serial Range 6101761 - 9999999
Ref No 9
Part Number 76131-V09-D01
Description PLATE, ROLLER
Serial Range 1000001 - 9999999
Qty
Price $8.30
Ref No 10
Part Number 76132-V09-D01
Description SPRING, RETURN (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $24.08
Ref No 11
Part Number 76133-V09-D01
Description HOOK, SPRING
Serial Range 1000001 - 9999999
Qty
Price $1.60
Ref No 12
Part Number 76134-V09-D01
Description SHAFT, TENSIONER (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $29.50
Ref No 13
Part Number 76135-V09-D01
Description PLATE, TENSION
Serial Range 1000001 - 9999999
Qty
Price $9.34
Ref No 14
Part Number 76136-V09-D01
Description ROLLER B, TENSIONER (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 15
Part Number 76137-V09-D01
Description SPACER, IDLER (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 16
Part Number 76138-V09-D01
Description SHIELD, IDLER (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 17
Part Number 76139-V09-D01
Description CAP, PIVOT
Serial Range 1000001 - 9999999
Qty
Price $8.30
Ref No 18
Part Number 76140-V09-D01
Description PULLEY, DRIVEN (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $288.24
Ref No 19
Part Number 76143-V09-D01
Description HANDLE, TENSION
Serial Range 1000001 - 9999999
Qty
Price $21.14
Ref No 20
Part Number 76181-V09-D01
Description V-BELT, BLADE (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 21
Part Number 76182-V09-D01
Description V-BELT, DECK (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 22
Part Number 76212-V09-D01
Description SHAFT, BLADE
Serial Range 1000001 - 9999999
Qty
Price $36.34
Ref No 23
Part Number 90101-V09-D01
Description BOLT, CARRIAGE (8X25)
Serial Range 1000001 - 9999999
Qty
Price $0.42
Ref No 24
Part Number 90102-V09-D01
Description SCREW, HEX. (3/4"X5.5")
Serial Range 1000001 - 9999999
Qty
Price $13.18
Ref No 25
Part Number 90103-V09-D01
Description BOLT, CARRIAGE (8X30) (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 26
Part Number 90105-V09-D01
Description BOLT, CARRIAGE (8X50)
Serial Range 1000001 - 9999999
Qty
Price $1.24
Ref No 27
Part Number 90106-V09-D01
Description BOLT, HEX. (8X40) (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 28
Part Number 90123-V09-A01
Description BOLT, FLANGE (10X20)
Serial Range 1000001 - 9999999
Qty
Price $0.94
Ref No 29
Part Number 90301-V09-A01
Description NUT, FLANGE (8MM)
Serial Range 1000001 - 9999999
Qty
Price $1.78
Ref No 30
Part Number 90301-V09-D01
Description NUT, HEX. (3/4")
Serial Range 1000001 - 9999999
Qty
Price $2.72
Ref No 31
Part Number 90302-V09-A01
Description NUT A, LOCK (8MM)
Serial Range 1000001 - 9999999
Qty
Price $2.48
Ref No 32
Part Number 90303-V09-D01
Description NUT, SPINDLE
Serial Range 1000001 - 9999999
Qty
Price $4.26
Ref No 33
Part Number 90304-V09-A01
Description NUT B, LOCK (8MM) (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 34
Part Number 90523-V09-A01
Description WASHER, HOUSING MOUNT (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 35
Part Number 90524-V09-A01
Description WASHER, SPINDLE (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 36
Part Number 90528-V09-A01
Description WASHER, FLAT (8.4X17X1.6)
Serial Range 1000001 - 9999999
Qty
Price $0.20
Ref No 37
Part Number 90760-V09-A01
Description PIN, DRAFT ARM COTTER
Serial Range 1000001 - 9999999
Qty
Price $0.14
Ref No 38
Part Number 90762-V09-A01
Description PIN, SPRING
Serial Range 1000001 - 9999999
Qty
Price $0.38
Ref No 39
Part Number 90951-V09-D01
Description NIPPLE, CUTTER DECK GREASE
Serial Range 1000001 - 9999999
Qty
Price $1.44
Ref No 40
Part Number 06727-V09-D01
Description BEARING, DRIVE
Serial Range 1000001 - 9999999
Ref No 40
Part Number 72010-V09-D01
Description SPINDLE SET (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $209.78
Ref No 41
Part Number 91053-V09-A01
Description BEARING A, CUTTER DECK (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 42
Part Number 91151-V09-A01
Description RETAINER, FRAME (NA USE ALT:06814-V09-D01)
Serial Range 1000001 - 9999999
Ref No 43
Part Number 91152-V09-A01
Description RETAINER
Serial Range 1000001 - 9999999
Qty
Price $3.68
Ref No 44
Part Number 91251-V09-D01
Description OIL SEAL, SPINDLE (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 45
Part Number 91551-V09-D01
Description SEAL, BUSHING (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 46
Part Number 91553-V09-D01
Description COLLAR, TENSIONER
Serial Range 1000001 - 9999999
Qty
Price $0.28
Ref No 47
Part Number 91560-V09-A01
Description BUSHING, PIVOT IDLER (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 48
Part Number 91564-V09-A01
Description BUSHING, DRIVE (NOT AVAILABLE)
Serial Range 1000001 - 9999999
Ref No 49
Part Number 06727-V09-D01
Description COLLAR, SPINDLE
Serial Range 1000001 - 9999999
Ref No 49
Part Number 72010-V09-D01
Description SPINDLE SET (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $209.78
Ref No 50
Part Number 72010-V09-D01
Description SPINDLE SET (SOURCE: VINTAGE PARTS INC.)
Serial Range 1000001 - 9999999
Qty
Price $209.78
Ref No 51
Part Number 76011-V09-A01
Description TENSIONER SET (NOT AVAILABLE)
Serial Range 6101761 - 9999999
